HFBR-1523, HFBR1521 (HFBR-x5xx Series) Versatile Link The Versatile Fiber Optic Connection

HFBR-1523 Description

www.DataSheet4U.com Versatile Link The Versatile Fiber Optic Connection Technical Data HFBR-0501 Series .
The Versatile Link series is a complete family of fiber optic link components for applications requiring a low cost solution.

HFBR-1523 Features

* Low Cost Fiber Optic Components
* Enhanced Digital Links dc-5 MBd
* Extended Distance Links up to 120 m at 40 kBd
* Low Current Link: 6 mA Peak Supply Current
* Horizontal and Vertical Mounting
* Interlocking Feature
* High Noise Immunity

HFBR-1523 Applications

* requiring a low cost solution. The HFBR-0501 series includes transmitters, receivers, connectors and cable specified for easy design. This series of components is ideal for solving problems with voltage isolation/insulation, EMI/RFI immunity or data security. The optical link design is simplified by

📥 Download Datasheet

This datasheet PDF includes multiple part numbers: HFBR-1523, HFBR1521. Please refer to the document for exact specifications by model.
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
HFBR-1523, HFBR1521
Manufacturer
Agilent
File Size
658.37 KB
Datasheet
HFBR1521_Agilent.pdf
Description
(HFBR-x5xx Series) Versatile Link The Versatile Fiber Optic Connection
Note
This datasheet PDF includes multiple part numbers: HFBR-1523, HFBR1521.
Please refer to the document for exact specifications by model.
