AA88347A 8-BIT DAC

The AA88347A is a CMOS processed digital to analog converter (DAC) with 8-bit resolution, low leakage and operating current. The AA88347A has 8 channels with build in operational amplifier output buffers which could operate in the full-swing voltage range from VCC to GND and enhance the Drive/Sink a.

AA88347A Features

* tia

* 12 bits serial data input (3 wire serial data transfer method, DI, CLK, LD)

* R-2R resistor ladder used for D/A conversion

* 8 channels with 8-bit resolution monotonic D/A converter

* 8 channels buffer operational amplifiers operating in the full voltage range f
