SST4393 Single N-Channel JFET switch
Linear Systems replaces discontinued Siliconix SST4393
FEATURES DIRECT REPLACEMENT FOR SILICONIX SST4393 LOW ON RESISTANCE rDS(on) ≤ 100Ω LOW GATE OPERATING CURRENT ID(off) = 5pA FAST SWITCHING t(ON) ≤= 15ns SST4393 Benefits: ABSOLUTE MAXIMUM RATINGS1 @ 25°C (unless otherwise noted) Low Error Voltage Maximum Temperatures High-Speed Analog Circuit Performance Storage Temperature ‐65°C to +200°C Negligible “Off-Error,” Excellent Accuracy Good Frequency Response, Low Glitches Operating Junction Temperature ‐55°C to +200°C Eliminates Additional Buffering Maximum Power Dissipation Continuous Power Dissipation 350mW SST4393 Applications: MAXIMUM CURRENT Analog Switches Gate Current (Note 1) IG = 50mA Choppers, Sample-and-Hol
SST4393 Datasheet
