JC(T
JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD
SOT-23 Encapsulate Adjustable Reference Source
CJ432 Adjustable Accurate Reference Source
DEVICE DESCRIPSION The CJ432 is a three-terminal Shunt Voltage Reference providing a highly accurance 1.24V. The CJ432 thermal stability and wide operating current, makes is sritable for all variety of applications that are looking for a low cost solution with high performance.
Features z Low dynamic output impedance z The effective temperature pensation in the working range of full temperature z Low output noise voltage z Fast on -state response z Sink current capability of 0.1mA to100mA
SOT-23
1. REFERENCE 2. CATHODE 3. ANODE
APPLICATION...
