MDD255-16N1 - Standard Rectifier Module

Features

  • / Advantages:.
  • Package with DCB ceramic.
  • Improved temperature and power cycling.
  • Planar passivated chips.
  • Very low forward voltage drop.
  • Very low leakage current.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MDD250 HIgh Power Diode IXYS Corporation
MDD250-08N1 HIgh Power Diode Modules IXYS Corporation
MDD250-12N1 HIgh Power Diode Modules IXYS Corporation
MDD250-14N1 HIgh Power Diode Modules IXYS Corporation
MDD250-16N1 HIgh Power Diode Modules IXYS Corporation

Other Datasheets by IXYS (Littelfuse)

Part Number Description
MDD255-12N1 Standard Rectifier
MDD255-14N1 Standard Rectifier Module
MDD255-18N1 Standard Rectifier
MDD255-20N1 Standard Rectifier
MDD255-22N1 Standard Rectifier

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Standard Rectifier Module Phase leg Part number MDD255-16N1 2 1 3 MDD255-16N1 VRRM I FAV VF = 2x 1600 V = 270 A = 1,08 V Backside: isolated Features / Advantages: ● Package with DCB ceramic ● Improved temperature and power cycling ● Planar passivated chips ● Very low forward voltage drop ● Very low leakage current Applications: ● Diode for main rectification ● For single and three phase bridge configurations ● Supplies for DC power equipment ● Input rectifiers for PWM inverter ● Battery DC power supplies ● Field supply for DC motors Package: Y1 ● Isolation Voltage: 4800 V~ ● Industry standard outline ● RoHS compliant ● Height: 30 mm ● Base plate: DCB ceramic ● Reduced weight ● Advanced power cycling Disclaimer Notice Information furnished is believed to be accurate and reliable.
