Features and benefits

/ Advantages:
* Planar passivated chips
* Very low leakage current
* Very low forward voltage drop
* Improved thermal behaviour Applications:
* Diode.

Application

* Diode Bridge for main rectification Package: SMPD
* Isolation Voltage: 3000 V~
* Industry convenient out.

Description

D = Diode L = Low Voltage Standard Rectifier A = (up to 1200V) 100 = Current Rating [A] B = 1~ Rectifier Bridge 1200 = Reverse Voltage [V] LB = SMPD-B Ordering Standard Alternative Ordering Number DLA100B1200LB-TUB DLA100B1200LB-TRR Marking on Pro.
