AiP16C22 - LCD Controller

Download the AiP16C22 datasheet PDF. This datasheet also covers the AiP16C22-I variant, as both devices belong to the same lcd controller family and are provided as variant models within a single manufacturer datasheet.

General Description

http://www.i-core.

P.C.

Wuxi I-CORE Electronics Co., Ltd.

Key Features

  • Operating voltage: 2.4 to 5.5V I2C interface Low power consumption Versatile blinking modes Read/Write address auto increment Internal 32kHz RC oscillator Bias: 1/2 or 1/3; duty: 1/4 16-step VLCD voltage adjustable 44×4 bit display data register Internal LCD bias generator with voltage follower Two selectable LCD frame frequencies: 80Hz or 160Hz LCD drive voltage can be adjusted by external resistor Maximum display pattern 44×4 44 SEGs×4 COMs Packaging information: LQFP48/LQFP52 Ordering Infor.

📥 Download Datasheet

Note: The manufacturer provides a single datasheet file (AiP16C22-I-CORE.pdf) that lists specifications for multiple related part numbers.

Datasheet Details

Part number AiP16C22
Manufacturer I-CORE
File Size 2.32 MB
Description LCD Controller
Datasheet download datasheet AiP16C22 Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
AIP3D15A060Q4T Dual-In-Line Package Intelligent Power Module Alpha & Omega Semiconductors
AIP3D20A060Q4 Dual-In-Line Package Intelligent Power Module Alpha & Omega Semiconductors
AIP3D20A060Q4N Dual-In-Line Package Intelligent Power Module Alpha & Omega Semiconductors
AIP3D30A060Q4 Dual-In-Line Package Intelligent Power Module Alpha & Omega Semiconductors
AIP3D30A060Q4N Dual-In-Line Package Intelligent Power Module Alpha & Omega Semiconductors

Other Datasheets by I-CORE

Part Number Description
AiP16C23 LCD Controller
AiP1628 keyboard scanning LED driver controller
AIP1629 LED drive controller
AIP1629A LED drive controller
AIP1629C LED drive controller

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Wuxi I-CORE Electronics Co., Ltd. Tab: 835-12 rev:B3 Number: AiP16C21-AX-XS-A066EN AiP16C22 Ram Mapping 44 SEG/4 COM LCD Controllers with 2-line Serial Interface Product Specification Specification Revision History Version Date 2021-04-A1 2021-04 New Description Address:Building B4,NO.777,Jianzhu Road,Binhu District,Wuxi City,Jiangsu Province http://www.i-core. cn P.C. 214072 1/ 25 VER 2021-04-A1 Wuxi I-CORE Electronics Co., Ltd. Tab: 835-12 rev:B3 Number: AiP16C21-AX-XS-A066EN 1 General Description AiP16C22 is a standard I2C interface communication LCD controller/driver. The device provides one display mode: 1/4 duty display modes. The maximum display segments of the device are 176 patterns (44×4).
