FSBB20CH60F - Motion SPM 3 module

Datasheet Summary

Description

FSBB20CH60F is a Motion SPM® 3 module providing a fully-featured, high-performance inverter output stage for AC Induction, BLDC, and PMSM motors.

Features

  • UL Certified No. E209204 (UL1557).
  • 600 V - 20 A 3-Phase IGBT Inverter with Integral Gate Drivers and Protection.
  • Built-In Thermal Shutdown Function.
  • Low-Loss, Short-Circuit Rated IGBTs.
  • Very Low Thermal Resistance Using Al2O3 DBC Sub- strate.
  • Dedicated Vs Pins Simplify PCB Layout.
  • Separate Open-Emitter Pins from Low-Side IGBTs for Three-Phase Current Sensing.
  • Single-Grounded Power Supply.
  • Isolation Rating: 2500 Vrm.

📥 Download Datasheet

Datasheet preview – FSBB20CH60F

Datasheet Details

Part number FSBB20CH60F
Manufacturer Fairchild Semiconductor
File Size 610.60 KB
Description Motion SPM 3 module
Datasheet download datasheet FSBB20CH60F Datasheet
